Alloy Steel Grease Injection Control Head with 10000psi Working Pressure and Hammer Union Connection for Wireline Operations
Alloy Steel Grease Injection Control Head with 10000psi Working Pressure and Hammer Union Connection for Wireline Operations Alloy Steel Grease Injection Control Head with 10000psi Working Pressure and Hammer Union Connection for Wireline Operations
Contactar ahora

Alloy Steel Grease Injection Control Head with 10000psi Working Pressure and Hammer Union Connection for Wireline Operations

Cantidad de orden mínima : 1 set Precio : USD 1-10000/set
Detalles de empaquetado : Pollywood Tiempo de entrega : 30-50 días
Condiciones de pago : L/C, T/T, D/P Capacidad de la fuente : 10 set/mes
Lugar de origen: PORCELANA Nombre de la marca: ZZ TOP OIL TOOLS
Certificación: ISO, API Número de modelo: Cabezal de control de inyección de grasa

Información detallada
Producto: Cabezal de control de inyección de grasa Material: Acero aleado
Presión de trabajo: 10000psi Solicitud: Operación del cable metálico
Uso: Equipos de control de presión de línea fija Conexión: unión de martillo
Temperatura de trabajo.: -29～121℃
Resaltar:

10000psi Grease Injection Control Head

,

Hammer Union Grease Injection Control Head

,

Alloy Steel Wireline Pressure Control Equipment

Descripción de producto

Grease Injection Control Head Assembly with Stuffing box and Wireline Wiper

The Grease Injection Control Head is a sealing device designed for braided cable wireline operations, providing effective wireline sealing functionality. This essential component is used across various oil and gas well applications where pressure control is critical during wireline operations, particularly when fluid or gas loss cannot be tolerated.

Key Features
  • Positioned at the top of the pressure control equipment string
  • Combines Line Wiper Bell, Stuffing Box, Flow Tubes assembly, and ball check valve
  • Essential for maintaining well integrity during high-pressure operations
Technical Specifications
Wire Size Working Pressure Qty. Of Stuffing Box Qty. Of Flow Tubes Qty. Of Hydraulic Port Qty. Of Grease Injection Port Qty. Of Grease Return Port Service Working Temperature
7/32"
5/16"
15/32"		 5000Psi 1 4 2 1 1 STD or H2S P+U -20°F~+250°℉
Or As Required
10000Psi 1 6 2 1 1
15000Psi 2 9 3 2 1
Alloy Steel Grease Injection Control Head with 10000psi Working Pressure and Hammer Union Connection for Wireline Operations 0
